APPLICATION
Suitable for all gas and liquid media that will not obstruct the pressure system or attack copper alloy parts.Useful for system that are not submited to strong vibrations . Specially designed for pneumatic hydraulics .
For water pressure test service
Case : black steel case
Wetted parts: brass
Standard : EN837 or DIN
Quality :100% inspected
Options/Notes: With brass water test hose
Maximum pressure memery pointer for option
Specifications:
Dial | 2”(50mm) |
Case | Black steel case |
Lens | Snap on acrylic |
Ring | |
Socket | Brass |
rang | 0-300psi |
Connection | 3/4" NPT Female hose |
Bourdon Tube | Phosphor bronze, |
Movement | Brass |
Pointer | Aluminum, black |
Over-Pressure Limit | 25% |
Accuracy | ±2.5% |
Welding | Copper alloy |
Enclosure Rating | IP43 |
