APPLICATION
Gaseous and dry media
Case : Stainless steel DIN bayonet ring
Wetted parts: brass
Standard : EN837 or DIN
Quality :100% inspected
Options/Notes: Lower, back entry, or surface or panel mount
with stainless steel case as option
Specifications:
Dial | Ø 100 |
Case | Stainless steel DIN bayonet ring |
Lens | Glass /plastic window |
Ring | DIN bayonet ring |
Socket | Brass |
rang | -600-0. 0-25 to 600mbar |
Connection | 1/2BSP ,G, BSPT ,NPT |
Bourdon Tube | Brass capsule |
Movement | brass |
Pointer | Aluminum, black |
Over-Pressure Limit | 25% |
Accuracy | ±3% |
Welding | |
Enclosure Rating | IP54 |
