1. APPLICATION
Suitable for all gas and liquid media that will not obstruct the pressure system or attack copper alloy parts. Specially designed for difficult conditions of use, as there are vibrations or quick changes of pressure. Also useful for adverse ambients.
Designation | Black steel case, crimped ring, liquid fillable |
Applications | Adverse service conditions where pulsation or vibration exists |
Nominal size: (mm) | Ø(40, 50, 63, 75, 100) |
Scale ranges | - 1 to 400 bar |
Accuracy class | 2.5 Ø (40-50), 1.6 Ø (63-100) |
Pressure connection | 1/8" Ø(40) 1/4" Ø(50, 63, 75, 100) 1/2" Ø(100) |
Wetted parts | Copper alloy |
Case material | Black Steel, crimped ring |
Window | Polycarbonate |
IP class | IP 65 |
Options/notes | Lower, back entry, Ø 63 and Ø100 with option of panel mount or surface mount |
