APPLICATION
For gaseous and liquid media that are not highly viscous or crystallizing and will not attack copper alloy parts, indication of cylinder charging pressure, respiratory protective equipment, sports weapons, welding engineering (compact equipment), medical engineering
Case : Brass, hexagon shape, chrome plated, SW27
Wetted parts: brass
Standard : EN837 or DIN
Quality :100% inspected
Options/Notes: Back entry with square body
Specifications:
Dial | 28MM |
Case | Brass, hexagon shape, chrome plated |
Lens | Plastic |
Ring | |
Socket | Brass |
rang | 0-1 to 25bar 0-100 to 400bar |
Connection | 1/8NPT 1/8 G 1/8BSPT |
Bourdon Tube | Brass |
Movement | Brass |
Pointer | Aluminum, black |
Over-Pressure Limit | 25% |
Accuracy | ±4% |
Welding | |
Enclosure Rating | IP43 |
