APPLICATION
Small size
Case : stainless steel
Wetted parts: brass
Standard : EN837 or DIN
Quality :100% inspected
Options/Notes: Back entry
Rubber boot for option
Specifications:
Dial | Ø(25, 30, 36, 40, 50) |
Case | Stainless steel |
Lens | Polycarbonate |
Ring | |
Socket | Brass |
rang | 0-1 to 25bar 0-100 to 400bar |
Connection | 1/8NPT 1/8 G 1/8BSPT brass |
Bourdon Tube | Stainless steel spiral tube |
Movement | |
Pointer | Aluminum, black |
Over-Pressure Limit | 25% |
Accuracy | ±4% |
Welding | |
Enclosure Rating | IP43 |
