1. APPLICATION
Suitable for all gas and liquid media that will not obstruct the pressure system or attack copper alloy parts. Specially designed for difficult conditions of use, as there are vibrations or quick changes of pressure. Also useful for adverse ambients.
Specification | Parameters |
Regular Specification | 1.5",2",2.5",4" |
Connection Thread | 1.5 ",connector thread 1/8 |
2",2.5", connector thread 1/4 | |
4", connector thread 1/2 | |
Pressure Range | -1-0，0-400 bar |
Pressure range of coupling | -1-24 bar |
Environmental temperature | -40-60℃ |
Material | 304Stainless steel shell,Stainless steel rolling ring, glass surface. Copper movement, copper joint. |
Standard of joint thread | BSP /NPT /BSPT / G standard |
Liquid filled medium | Glycerin or silicone oil |
